Baffle system - hollow core sphere
- Consists of 3 interlocking rings
- Lock without fasteners
- High strength plastic
Liquid Surge Stabilizers
Designed to stabilize the movement of liquid cargo in partially loaded tankers during transport. Eliminates the “wave” that can form inside the tank from the liquid surging back and forth when the truck stops or starts, preventing the dangerous push of the truck in the direction the wave is moving.
All Products
Traffic Product Type
- Barricades
- Type I & II Barricades
- Type III Barricades
- Barricade Lights
- Channelizers
- Cones & Cone Bars
- Curb Ramps
- Delineators
- Glare Screen
- Liquid Surge Stabilizers
- Roll-Up Signs
- Rubber Products
- Safety Signage
- Speed Bumps, Humps, & Parking Stops
- Trench Covers
- Watchdog Traffic Control Sign Stands
- Water Filled Barricades
- Wheel Chocks
Fluid passes through baffle removing surge
- 12 flow restriction ports around each ring, 36 in total
- Improves vehicle handling
- Reduces tank stress
No tools required
- Simple, fast assembly
- No attachment to tank
- No retrofit problems
Compatible with metal, poly, and fiberglass tanks
- Designed for tanks with or without fixed baffles or compartments
Fits 16" manways or larger
Packs flat
- Low cost shipping
Made in the U.S.A.
-
State Reference Guide
This product is not part of our State Reference Guide.
-
Additional Information
Not recommended for flammable or food grade liquids.
-
Specifications
Sold in boxes of 28 sets. Each set consists of 3 rings.
Part Number: LSS1575BOXSET
Outside of ring is 15.5"W
